Edwards ESDP/GVSP30/30A Major Repair Kit

Edwards ESDP/GVSP30/30A Major Repair Kit

Part Number: 71004800

$1,499.00

71004800

DESCRIPTION PART NO. QTY
Crank Pin Assembly 71004006 3
Viton O-Ring E06995973 1
Grease Seal E07193002 1
Spring E08801050 1
Exhaust Valve E08802390 1
Viton Shaft Seal E08804072 1
Exhaust Valve Spring E08804390 1
Outlet Valve Guide E08805041 1
Valve Stem E08805380 1
Needle Bearing E08880020 2
Black Coupling Insert E08881000 1
Viton Shaft Seal E08882100 1
Grease Seal w/Spring E08882150 2
Crank Needle Bearing E08884001 3
Needle Bearing E08884010 1
Viton Shaft Seal E08885012 1
Viton O-Ring E320086 6
Viton O-Ring E320087 1
Viton O-Ring E320121 1
Scroll Pump Motor Bearing E330008 1
Clear Mylar Scroll Washer E420039 4
Tip Seal Kit E71004026 1
5 oz. Tube Grease E870014 1
Viton O-Ring L20019794 1
Viton O-Ring L23970304 1
