Edwards E2M275 Major Repair Kit 36701831
Part Number: 36701831
$1,295.00
| DESCRIPTION | PART NO. | QTY |
| Dowty Seal | E02104001 | 1 |
| Dowty Seal | E02104002 | 6 |
| Dowty Seal | E02104004 | 2 |
| Dowty Seal | E02104008 | 1 |
| Viton Shaft Seal | E02109077 | 3 |
| Viton Shaft Seal | E02109120 | 1 |
| O-Ring | E02120027 | 3 |
| O-Ring | E02122036 | 1 |
| O-Ring | E02125011 | 1 |
| O-Ring | E02125020 | 2 |
| O-Ring | E02125023 | 1 |
| O-Ring | E02125026 | 2 |
| O-Ring | E02125039 | 1 |
| O-Ring | E02125055 | 1 |
| O-Ring | E02125091 | 1 |
| O-Ring | E02125116 | 1 |
| O-Ring | E02125171 | 1 |
| O-Ring | E02125181 | 1 |
| O-Ring | E02126047 | 1 |
| O-Ring | E02126050 | 2 |
| Piston Face | E02800016 | 1 |
| 2nd Stage Vane | E20402087G | 2 |
| Oil Pump Vane | E20402098G | 1 |
| 1st Stage Vane | E20402129G | 2 |
| Roller Bearing | E20404013 | 2 |
| Inner Ring | E20405007 | 1 |
| Shaft Seal Sleeve | E20405021 | 1 |
| Filter Element | E22304032 | 1 |
| Felt Ballast Filter | E22305041 | 2 |
| Gas Ballast Valve | E25904601 | 1 |
| Piston Ring | E26501020 | 1 |
| Distributor Rubber | E27159413 | 1 |
| Diaphragm | E27159416 | 1 |
| Gas Ballast Gasket | E27159428 | 1 |
| Viton Exhaust Valve | E27159504 | 1 |
| Exhaust Rubber Valve | E27159505 | 1 |
| Exhaust Rubber Valve | E27159506 | 1 |
| Filter Gasket | E27159526 | 1 |
| Ballast Gasket | E27159614 | 1 |
| Ballast Gasket | E27159615 | 1 |
| Valve Body Gasket | E27159619 | 1 |
| Exhaust Gasket | E27159620 | 1 |
| End Plate Gasket | E27159621 | 1 |
| Lid Gasket | E27159624 | 1 |
| Lid Gasket | E27159625 | 1 |
| Oil Box Gasket | E27159627 | 1 |
| Box Gasket | E27159628 | 1 |
| Valve Pad | E34601042 | 1 |
| Back Up Washer | E34601067 | 2 |
